Description

Planetary Ball Mills are used wherever the highest degree of fineness is required. Apart from the classical mixing and size reduction processes, the mills also meet all the technical requirements for colloidal grinding and have the energy input necessary for mechanical alloying processes. The extremely high centrifugal forces of the Planetary Ball Mills result in very high pulverization energy and therefore short grinding times.

The PM 100 CM is a convenient benchtop model with 1 grinding station. It operates in centrifugal mode mode, which leads to a more gentle size reduction process with less abrasion.

Features
  • Powerful and quick grinding down to nano range
  • Perfect stability on lab bench thanks to FFCS technology
  • Innovative counter weight and imbalance sensor for unsupervised operation
  • Gentle grinding in centrifugal mode
  • Comfortable parameter setting via display and ergonomic 1-button operation
  • Automatic grinding chamber ventilation
  • 10 SOPs can be stored
  • Programmable starting time
  • Power failure backup ensures storage of remaining grinding time
  • Reproducible results due to energy and speed control
  • Suitable for long-term trials and continuous use
  • 2 different grinding modes (dry and wet)
  • Optional pressure and temperature measuring system PM GrindControl
  • Measurement of energy input
  • Wide range of materials for contamination free grinding
  • Safety Slider for safe operation

  • Detailed Specifications
  • ItemPlanetary Ball Mill PM 100
  • CompanyRETSCH GmbH
  • PriceGet Quote
  • Catalog NumberPM 100
  • QuantityEA
  • PrincipleImpact and Friction
  • Sample TypeSoft, Hard, Brittle or Fibrous - Dry or Wet
  • Dimensions(WxHxD) 630 x 468 x 415 mm
  • ApplicationsPulverizing, Mixing, Homogenizing and Colloidal Milling: Agriculture, Biology, Chemistry / Plastics, Construction Materials, Engineering / Electronics, Environment / Recycling, Geology / Metallurgy, Glass / Ceramics, Medicine / Pharmaceuticals
  • Sample Size< 10 mm
  • Speed100 to 650 min-1
  • Rotor Typegrinding jar and balls
  • Final Fineness< 1 um or < 0.1 um for Colloidal Grinding
