Description

Panasonic MDF-C8V1 ultra-low temperature freezer maintains internal temperatures as low as -80°C. All models use Panasonic uniquely designed compressors for ultra-low temperature applications. Manufactured with VIP® PLUS insulation, they are ideally suited for use in laboratories and hospitals for long-term preservation and storage of blood, specimens and components, as well as materials testing. Advanced features include VIP® PLUS technology, a microprocessor based temperature control system with LED digital temperature display, a platinum resistance temperature sensor for extra precision and reliability, a power failure warning system with built-in audible and visible indicators, filterless refrigeration circuit, and temperature alarm.

Features
  • Outstanding Reliability and Performance
  • Application Specific Ultra Low Temperature Compressor
  • Ideal -80°C freezing environment using new VIP® PLUS insulation technology maximizes storage capacity
  • Newly developed single-compressor system achieves higher energy efficiency and space saving construction
  • Convenient maintenance with filterless structure that makes filter cleaning unnecessary
  • Microprocessor temperature control with digital input for precise setting and control
  • Built-in audible and visible temperature and power failure alarms

Biomedical Freezers

Panasonic MDF Series biomedical freezers offer outstanding reliability and performance for a wide variety of storage and research applications.
  • In medical applications, they provide effective storage of life-saving fresh and frozen blood supplies and vaccines, as well as samples for diagnosis.
  • In the biotechnology installations, they provide effective storage of enzymes for genetic research, as well as culture media, reagents and samples for testing.
  • In the industrial field, they are ideal for aging and temperature tests on electronic components, precision devices, and compound resins.

As a storage environment, with excellent safety features, easy operability, and efficiency, these freezers offer unsurpassed reliability and functionality. If you are looking for precision temperature controlled storage equipment, look to Panasonic.

Enhanced Operation
  • Front-mounted display/control panel (with new microprocessor) located at convenient waist height
  • Memory backup
  • Temperature display
  • Front access calibration for 7-day temperature recorder
  • The control panel, alarm system and non-volatile memory are the same for all three models in the series.
  • Single electrical box makes servicing simpler.
  • The chamber temperature is displayed for five seconds if buzzer key is depressed during power failure alarm.
  • After a power outage, operation resumes at pre-outage settings (non-volatile memory for temperature and alarm temperature settings)
  • Control panel can be reset to zero for validation
  • Two access ports (right-hand side and bottom left)
  • Four casters and two adjustable feet

SANYO Biomedical Solutions is now Panasonic

  • Detailed Specifications
  • Item-80C Ultra-Low Temperature VIP PLUS Freezer
  • CompanyPanasonic Healthcare Corporation of North America
  • PriceGet Quote
  • Catalog NumberMDF-C8V1
  • Temperature Range-50 to -86C
  • Exterior Dimensions(WxDxH) 550 x 685 x 945 mm
  • Interior Dimensions(WxDxH) 405 x 490 x 430 mm
  • Volume3 cu.ft.
  • QuantityEA
  • OrientationChest
  • ShelvesInquire
  • Voltage115V
