Description

ELTRA’s CS-580 analyzer allows precise measurement of carbon and sulfur, from trace level up to 100% in solid materials. Typical samples include coal, coke, oil, ashes, catalysts, lime, gypsum, building materials, soils, rubber, leaves, soot, tobacco, waste, and many more. The CS-580 analyzer is equipped with a high temperature resistance furnace (up to 1550°C) for treatment and oxidation of the sample. The detection system of the CS-580 is very sensitive and guarantees a long lifetime. It can be customized according to the user’s requirements. Up to four infrared cells can be combined independently, allowing for highly precise measurements.

Features
  • Simultaneous measurement of C and S in one sample
  • ASTM compliant
  • Tailor-made configuration with up to 4 measuring channels
  • Highest precision from ppm level to 100%
  • Infrared path of solid gold for demanding samples
  • Maintenance-friendly
  • Economical cost of ownership

  • Detailed Specifications
  • ItemCS-580 Carbon / Sulfur Analyzer for Organic Samples
  • CompanyELTRA GmbH
  • PriceGet Quote
  • Catalog NumberCS-580
  • Temperature Rangeup to 1550 C
  • QuantityEA
  • Sensitivityfrom ppm levels
  • Detector(s)1 to 4 IR Detectors
  • Sample VolumeInquire
  • PrincipleCombustion in resistance furnace and infrared detection
  • Measuring Range25 to 500 mg (carbon), 10 to 100 mg (sulfur)
  • Measurement Mode(s)Sulfur, Carbon
  • Oxidation MethodThermal Combustion
  • Detection Limit5 ug (carbon), 1 ug (sulfur)
  • Measurement AccuracyInquire
  • Measuring Time60 to 120 s
  • Sample Weight5 to 500 mg (standard applications)
  • MethodInfrared Detection
  • Carbon Measurement Rangefrom ppm level to 100%
  • Sulfur Measurement Rangefrom ppm level to 100%
