Copolymers pose unique challenges in gel permeation chromatography (GPC) compared with their homopolymer counterparts, especially because commercially available standards with the same composition are unlikely to exist, making standard GPC calibration much less straightforward.1 This often forces laboratories to adopt more flexible strategies involving additional detectors. This guide will provide some high-level considerations when buying a new GPC system or when upgrading or expanding an existing GPC for copolymer analysis.
Detectors
GPC detectors monitor the concentration and physical properties of polymers as they elute, allowing their molecular weight and distribution to be determined. GPC runs for homopolymers often use a single detector to obtain a relative molecular weight, whereas copolymers may require multiple detectors to decouple molecular weight from compositional variations. Because GPC separates polymers by hydrodynamic volume rather than chemical composition, copolymers with varying composition can exhibit additional complexity in data interpretation.
Refractive Index (RI) Detectors
RI detectors are the most common detector type, as they do not require a copolymer to have chromophores. Their disadvantages are their lower sensitivity compared to UV detectors, and they are also highly sensitive to the environmental conditions of your lab, especially temperature. As RI detectors measure the difference in refractive index between the sample and reference cell containing pure solvent, they require the use of a reference cell.
UV Detectors
UV detectors have a high selectivity, and the UV analysis wavelength can be set to detect only one comonomer, or even an end group. This enables them to provide compositional information, which provides valuable information for copolymer analysis. They are also more sensitive than RI detectors, so if you’re working with trace amounts of a copolymer with chromophores, a UV detector can help reduce the amount of material needed for a GPC run. However, UV detectors can only be used if the copolymer bears UV-active chromophores.
Viscometers
Viscometers are suitable for copolymer analysis when the polymers behave as random coils, and universal calibration based on intrinsic viscosity provides reasonably accurate molecular weights without requiring exact standards. This method is less reliable for copolymers with branching, rigid structures, or strong compositional heterogeneity, since the Mark-Houwink relationship varies with architecture and composition.
Light Scattering Detector
For the highest accuracy with novel copolymers, many labs use multi-angle light scattering (MALS) to measure the molecular weight (Mw) without relying on calibration standards, but it requires an accurate dn/dc value. For copolymers, this can be challenging because dn/dc depends on polymer composition, which can vary across the elution profile. In GPC, each point in the chromatogram corresponds to a different fraction of the polymer population. For copolymers, each elution slice will have a different monomer ratio, leading to variation in dn/dc across the elution profile.2,3 It would be impossible to measure this value at each slice, so averaged or composition-estimated dn/dc values are often used, which can introduce additional uncertainty in copolymer analysis.4
Multiple Detectors
As noted , it’s important to know the limitations of your detector and whether it is compatible with the types of copolymers you expect to analyze now, or in the future. For example, not every polymer is UV-active, and using a UV detector alone will not provide usable chromatograms.
UV-RI
Refractive index (RI) detectors respond to all components in an eluent, while a UV detector can selectively detect only one comonomer.5 Each detector responds differently to the copolymer’s components, so their signals are shifted relative to one another, even after correcting for instrument delay. This shift reflects changes in the composition of the copolymer across the elution profile, and each detector emphasizes different parts of that composition.
UV-MALS-RI
A triple-detection system using UV/NIR, MALS, and RI detectors can determine copolymer composition when the components exhibit distinct responses to at least two detectors. In these systems, software combines signals from RI, MALS, and UV/NIR detectors to enable compositional analysis.6
Column Selection
Column Molecular Weight Range
Choose a column with an appropriate molecular weight range. If all or most of your polymer chains are bigger than the pores of the column, they will co-elute with the void volume instead of through the pores of the column, resulting in poor resolution. If you expect your polymer sample to have a wide PDI, such as when using free-radical polymerization for random copolymers, the molecular weights of some chains may exceed the range of a single column, and multiple columns can be used in series to expand the separation range.
Column Chemistry
GPC separates polymers based on hydrodynamic volume, ideally without additional interactions with the stationary phase. However, non-size interactions (e.g., ionic or hydrophobic interactions) may occur during GPC analysis of specific types of polymers, and the column chemistry must be carefully selected to minimize these effects. For example, polyelectrolytes such as poly(styrene sulfonic acid) (PSS) often require aqueous SEC columns with an appropriate ionic strength in the mobile phase to suppress electrostatic interactions. In such cases, aqueous SEC columns designed for polyelectrolytes (e.g., sulfonated or hydrophilic stationary phases such as TSKgel columns) may be appropriate.7
Column Temperature Range
If you’re using a column oven, make sure to also check that the column’s temperature range includes the temperature you’ll be performing your runs at. Operating above a column’s given temperature range may permanently damage it due to polymer gel collapse or shrinkage, which decreases the separation efficiency.
Column Ovens
Highly crystalline copolymers may require elevated temperatures to dissolve them in solvents, and this high temperature needs to be maintained during a GPC run to prevent them from precipitating out during the run and clogging your column.8 Column ovens are also essential when using a RI detector, even when a higher temperature isn’t necessary to ensure solubility, as even tiny temperature differences (0.1 oC) can cause baseline fluctuations.9
General Takeaways
From a purchasing perspective, the key decision in selecting GPC components is how much flexibility and accuracy your application requires. For routine work, a basic RI-based system may be enough, but when working with more complex copolymers, multiple detectors or even orthogonal methods like 1H NMR or mass spectrometry may become necessary to determine both the molecular weight and composition of your copolymers. Investing in a flexible, multi-detector platform upfront can help future-proof your GPC system as analytical demands expand.
